Kayak Outboard Motor Transom Mounted Kit
|
Installing A Four Stroke Honda® Air Cooled Motor On Any Kayak Is Now Simpler Than Ever!
|
Kayak Outboard Motor Transom Mounted Kit
Honda® 35cc four cycle motor kayak mounting bracket, twist handle speed controller, steering handle, or navigating arm for kayak foot pedal usage , kill switch lanyard , including all stainless steel hardware required for installation. Rated for saltwater and freshwater usage. Actual Honda Motor Image Please note when ordering this item you will need to choose from Option #1 or Option #2 Navigating Option 1 - Semi-Telescoping Steering Handle Navigation OR Navigating Option 2 - Navigation Arm for Kayaks Foot Pedal Navigating |
Option 1 - Semi-Telescoping Steering Handle Navigation
Item # 89111 Sale Price $1799.99
Option 2 - Navigation Arm for Kayaks Foot Pedal Navigating Item # 89222 Sale Price $1749.99
Note: Removal of existing rudder necessary.
|
|
|
|
Kayak Honda® Motor Transom Mounted Kit
Easy installation transom mount kits, that fit new and older kayaks with or without rudders.
Easy installation transom mount kits, that fit new and older kayaks with or without rudders.
- Outboard Transom Mount kits attach securely to your kayak with four stainless screws, eliminating any cut outs to the hull and any access hatches.
- The transom mounts are made from durable polypropylene composite for marine application, aluminum and stainless steel hardware.
- The outboard motor kit offers a low profile and small footprint in size making it easy for removal and storage.
- Features easy start remote cord to reach from forward seated position.
- Twist throttle cable designed to reach your seat, allowing speed control and retrofitted for safety, an instant kill switch lanyard.
OPTION 1 - Semi-Telescoping Steering Handle Navigation (Kayaks Without a Rudder)
The steering handle is adjustable to meet the different kayak lengths. No rudder, no problem: steer kayak with your hand.
The steering handle is adjustable to meet the different kayak lengths. No rudder, no problem: steer kayak with your hand.
OPTION 2 - Foot Pedal Navigation (Using Kayaks Rudder Cables)
Our system also allows the kayak to be navigated using the foot pedal cables from kayaks rudder system. Attach the rudder cable to motor, and now your have hands free kayaking.
Our system also allows the kayak to be navigated using the foot pedal cables from kayaks rudder system. Attach the rudder cable to motor, and now your have hands free kayaking.
|
Kayak Gas Trolling Motor Specifications
|
Engine Type: 35cc Honda Four Stroke
Cooling System: Forced Air Engine Output: 2.5 HP Carburetion: Gravity Speed: 6-7 mph* Starting System: Pull Start Weight: 19 lbs +/- Ignition (Coil Type): C.D.I. |
Spark Plug: CM5H (NGK), CMR5H (NGK)
Drive System: Forward / Neutral Trim Stages: 4 Steering: Twist Grip Throttle Control Oil Type: SAE 10w30 or SAE 30w Max. Operation Range (rpm): 4300 - 5000 Idle Speed In Forward Gear (rpm): 1100 Usage: Fresh Water & Salt Water |
Gear Reduction Ratio: 2:1
Number of Cylinders: 1 Clutch Type: Centrifugal Dry Pads Propeller (Blade x Diameter) 7” x 5” Propeller: Aluminum Exhaust System: Air Safety Switch: Remote Kill Switch Fuel: 87 Octane |
For sales and technical support, call (727) 501-3116
